World’s most complex synthetic microparticle outdoes nature’s intricacy

Creating and measuring intricacy in particles that could improve electronics and chemical reactions.

Synthetic microparticles more intricate than some of the most complicated ones found in nature have been produced by a University of Michigan-led international team of scientists and engineers. They also investigated how that intricacy arises and devised a way to measure it.

The findings, published in Science, pave the way for more stable fluid-and-particle mixes, such as paints, and new ways to twist light—a prerequisite for holographic projectors.

The particle is composed of twisted spikes arranged into a ball a few microns, or millionths of a millimeter, across.

Biology is a great creator of complexity on the nano- and microscales, with spiky structures such as plant pollen, immune cells, and some viruses. Among the most complex natural particles on the scale of the new synthetic particles are spiky coccolithophores. Also a few microns in diameter, this type of algae is known for building intricate limestone shells around themselves. To better understand the rules that govern how particles like these grow, scientists and engineers try to make them in the lab. But until now, there was no formalized way to measure the complexity of the results.

Microscope image of complex sheets of nanoparticles that look like a kayak
If the gold-cysteine nanosheets are designed to remain flat, the result is a moderately complex design that the researchers called a “kayak” particle. Credit: Wenfeng Jiang, Kotov Lab, University of Michigan.

“Numbers rule the world, and being able to rigorously describe spiky shapes and put a number on complexity enables us to use new tools like artificial intelligence and machine learning in designing nanoparticles,” said Nicholas Kotov, the Joseph B. and Florence V. Cejka Professor of Engineering at the University of Michigan, who led the project.

The team—which includes researchers at the Federal University of São Carlos and the University of São Paulo in Brazil, as well as the California Institute of Technology and the University of Pennsylvania in the U.S.—used the new framework to demonstrate that their particles were even more complicated than coccolithophores.

The computational arm of the team, led by André Farias de Moura, a professor of chemistry at the Federal University, investigated the quantum properties of the particles and the forces acting on the nanoscale building blocks.

One of the key players in producing complexity can be chirality—in this context, the tendency to follow a clockwise or counterclockwise twist. They introduced chirality by coating nanoscale gold sulfide sheets, which served as their particle building blocks, with an amino acid called cysteine. Cysteine comes in two mirror-image forms, one driving the gold sheets to stack with a clockwise twist, and the other tending toward a counterclockwise twist. In the case of the most complex particle, a spiky ball with twisted spines, each gold sheet was coated with the same form of cysteine.

Elaborate shell of a microorganism
The limestone shell produced by the coccolithophore Syracosphaera anthos, one of the most complex particles on this scale found in nature, is more intricate than kayak particles but less intricate than the spiky synthetic particle. Courtesy of www.mikrotax.org.

But the team also controlled other interactions. By using flat particles, they created spikes that were flat rather than round. They also used electrically charged molecules to ensure that the nanoscale components built themselves into larger particles, bigger than a few hundred nanometers across, due to repulsion.

“These laws often conflict with each other, and the complexity emerges because these communities of particles have to satisfy all of them,” said Kotov.

And that complexity can be useful. Nanoscale spikes on particles like pollen keep them from clumping together. Similarly, the spikes on these particles made by the research team help them disperse in virtually any liquid, a property that is useful for stabilizing solid/liquid mixtures such as paints.

The particles with twisted spikes also take in UV light and emit twisted—or circularly polarized—visible light in response.

“The understanding of these emissions was one of the hardest parts of the investigation,” said de Moura.

From the results of the experiments and simulations, it appears that UV energy was absorbed into the hearts of the particles and transformed through quantum mechanical interactions, becoming circularly polarized visible light by the time it left through the curved spikes.

The researchers believe that the tactics they have uncovered can help scientists engineer particles that improve biosensors, electronics, and the efficiency of chemical reactions.

The paper is titled, “Emergence of Complexity in Hierarchically Organized Chiral Particles,” and is published in the journal Science.

The research is funded by the U.S. Department of Defense, the National Science Foundation and the Brazilian funding agencies CAPES, CNPq and FAPESP.

The particles were studied at the Michigan Center for Materials Characterization.

Kotov is also a professor of materials science and engineering and macromolecular science and engineering.
